CSRA-24A-2-20-AR
ActiveR-K Electronics, Inc.
AC CURRENT, 24A, ADJ, 4-20A, AUT
CSRA-24A-2-20-AR
ActiveR-K Electronics, Inc.
AC CURRENT, 24A, ADJ, 4-20A, AUT
Description
General part information
CSRA-24A-2-20-AR
AC CURRENT, 24A, ADJ, 4-20A, AUT
Technical Specifications
Parameters and characteristics for this part
| Specification | CSRA-24A-2-20-AR |
|---|---|
| Delay Time (Maximum) | 20 s |
| Delay Time (Minimum) | 0.2 Sec |
| Features | Automatic Reset |
| Function | Overcurrent, Undercurrent |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 55 °C |
| Operating Temperature (Min) | 0 °C |
| Termination Style | Screw Terminal |
| Trip Current (Max) | 20 A |
| Trip Current (Min) | 4 A |
| Voltage - Supply | 24 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
