RER-S4C-D24

Active

Dinkle Corporation, USA

RELAY GEN PURPOSE SPDT 5A 24V

Search across all available documentation for this part.

Active

Dinkle Corporation, USA

RELAY GEN PURPOSE SPDT 5A 24V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay 4PDT (4 Form C) 24VDC Coil Socketable

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

RELAY GEN PURPOSE SPDT 5A 120V

Part	Coil Resistance	Mounting Type	Features	Coil Voltage	Coil Type	Contact Rating (Current)	Coil Current	Must Release Voltage	Release Time	Switching Voltage [Max]	Must Operate Voltage	Operate Time	Contact Material	Operating Temperature [Max]	Operating Temperature [Min]	Contact Form	Relay Type
Dinkle Corporation, USA RER-S4C-A120	4.43 kOhms	Socketable	Lighted Indicator	120 VAC	Non Latching	5 A	9.2 mA	36 VAC	20 ms	30 VDC, 250 VAC	96 VAC	20 ms	Silver Nickel (AgNi)	70 °C	-55 °C	4PDT (4 Form C)	General Purpose
Dinkle Corporation, USA RER-S4C-A230	4.43 kOhms	Socketable	Lighted Indicator	230 VAC	Non Latching	5 A	5.5 mA	69 VAC	20 ms	30 VDC, 250 VAC	184 VAC	20 ms	Silver Nickel (AgNi)	70 °C	-55 °C	4PDT (4 Form C)	General Purpose
Dinkle Corporation, USA RER-S4C-D24	640 Ohms	Socketable	Lighted Indicator	24 VDC	Non Latching	5 A	36.9 mA	2.4 VDC	20 ms	30 VDC, 250 VAC	18 VDC	20 ms	Silver Nickel (AgNi)	70 °C	-55 °C	4PDT (4 Form C)	General Purpose
