CMCP300SS-06-01-00

Active

STI Vibration Monitoring

JUNCTION BOX S STL GRY 8"L X 6"W

Search across all available documentation for this part.

Active

STI Vibration Monitoring

JUNCTION BOX S STL GRY 8"L X 6"W

Technical Specifications

Parameters and characteristics commom to parts in this series

JUNCTION BOX S STL 10"L X 8"W

Part	Container Type	Height [z]	Height [z]	Area (L x W) [custom]	Area (L x W) [custom]	Ratings	Design	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Color	Area (L x W)	Area (L x W)
STI Vibration Monitoring CMCP300SS-10-01-00	Junction Box	152.4 mm	6 in	80 in˛	516 cm˛	IP66, NEMA 4X	Cover Included	8 in	254 mm	10 in	203.2 mm	Gray
STI Vibration Monitoring CMCP300SS-06-01-00	Junction Box	101.6 mm	101.6 mm	47.9 in˛		IP66, NEMA 4X	Cover Included					Gray	309 cm˛
STI Vibration Monitoring CMCP300SS-12-01-00	Junction Box	152.4 mm	6 in	80 in˛	516 cm˛	IP66, NEMA 4X	Cover Included	8 in	254 mm	10 in	203.2 mm	Gray
STI Vibration Monitoring CMCP300SS-04-01-00	Junction Box	101.6 mm	101.6 mm			IP66, NEMA 4X	Cover Included	6 "	152.4 mm	6 in	152.4 mm	Gray	232 cm²	36 in²
STI Vibration Monitoring CMCP300SS-08-01-00	Junction Box	101.6 mm	101.6 mm			IP66, NEMA 4X	Cover Included					Gray

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 475.00

General part information

Junction Box Metal, Stainless Steel Gray Cover Included 8.000" L x 6.000" W (203.20mm x 152.40mm) X 4.000" (101.60mm)
