Specification	MN11SD3W01-CA

Actuator Length	13.1 mm
Actuator Material	Chrome Plated, Brass
Actuator Type	Standard Round with Cap
Bushing Thread	1/4-40
Circuit	SPST
Current Rating	4 A, 6 A
Electrical Life (Cycles)	25000
Illumination	Non-Illuminated
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Mounting Type	Panel Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-30 °C
Panel Cutout Diameter	6.5 mm
Panel Cutout Shape	Circular
Switch Function	On-Off
Termination Style	Solder Lug
Voltage Rating - AC	125 V
Voltage Rating - DC	30 V
