Part	Ingress Protection Description	Ingress Protection IP Rating	Operating Temperature (Max)	Operating Temperature (Min)	Shielding	Contact Shape	Shell Size - Insert	Shell Size - Insert	Number of Positions	Type	Connector Type	Contact Size	Orientation	Contact Type	Note	Contact Finish	Wire Gauge or Range - mm² (Maximum)	Wire Gauge or Range - mm² (Minimum)	Contact Material	Contact Finish Thickness	Wire Gauge or Range - AWG (Max)	Wire Gauge or Range - AWG (Min)	Contact Termination	Contact Finish Thickness - Mating	Color	Mounting Feature	Mounting Type	Shell Material	Contact Finish - Mating	Termination	Current Rating	Insert Material	Material Flammability Rating	Shell Finish	Fastening Type	Primary Material	Features
LEMO EGG.0B.405.YL	Dust Protected	IP50	250 °C	-55 °C	Unshielded	Circular	405	405	5	For Female Sockets	Insert	0.7 mm	G	Crimp Solder Cup	Contacts Not Included Insert Only Requires Shell
LEMO EGG.0B.655.ZZM										Machined Signal		0.7 mm		Socket		Gold	0.34 mm²	0.14 mm²	Bronze	59 µin	25.5 AWG	22 AWG	Crimp
LEMO EGG.0B.307.CLL	Dust Protected	IP50	250 °C	-55 °C	Shielded		307	307	7		Female Sockets Receptacle		G						Bronze					59 µin	Silver	Bulkhead Rear Side Nut	Panel Mount	Brass	Gold	Solder Cup	2.5 A	PEEK Polyetheretherketone	UL94 V-0	Chrome	Push-Pull	Metal
LEMO EGG.0B.307.ZLL	Dust Protected	IP50	250 °C	-55 °C	Shielded		307	307	7		Female Sockets Insert		G						Bronze					59 µin					Gold	Solder Cup	2.5 A	PEEK Polyetheretherketone	UL94 V-0				Insert Only Requires Shell
LEMO EGG.0B.303.CLN	Dust Protected	IP50	250 °C	-55 °C	Shielded		303	303	3		Female Sockets Receptacle		G						Bronze					59 µin	Silver	Bulkhead Rear Side Nut	Panel Mount Through Hole	Brass	Gold	Solder	8 A	PEEK Polyetheretherketone	UL94 V-0	Chrome	Push-Pull	Metal
LEMO EGG.0B.302.CYM	Dust Protected	IP50	250 °C	-55 °C	Shielded		302	302	2		Female Sockets Receptacle		G						Bronze					59 µin	Silver	Bulkhead Rear Side Nut	Panel Mount	Brass	Gold	Crimp	10 A	PEEK Polyetheretherketone	UL94 V-0	Chrome	Push-Pull	Metal
LEMO EGG.0B.306.ZLN	Dust Protected	IP50	250 °C	-55 °C	Shielded		306	306	6		Female Sockets Insert		G						Bronze					59 µin					Gold	Solder	2.5 A	PEEK Polyetheretherketone	UL94 V-0				Insert Only Requires Shell
LEMO EGG.0B.403.YL	Dust Protected	IP50	250 °C	-55 °C	Unshielded	Circular	403	403	3	For Female Sockets	Insert	0.9 mm	G	Crimp Solder Cup	Contacts Not Included Insert Only Requires Shell
LEMO EGG.0B.402.YL	Dust Protected	IP50	250 °C	-55 °C	Unshielded	Circular	402		2	For Female Sockets	Insert	0.9 mm	G	Crimp Solder Cup	Contacts Not Included Insert Only Requires Shell
LEMO EGG.0B.404.YL	Dust Protected	IP50	250 °C	-55 °C	Unshielded	Circular	404		4	For Female Sockets	Insert	0.7 mm	G	Crimp Solder Cup	Contacts Not Included Insert Only Requires Shell

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Connectors_High Voltage,Current Catalog

GMA.0B.035.DN | Datasheet

Datasheet
