FMC00706-6
ActiveFairview Microwave
CBL ASSY SMPPLUG-SMPJACK 6
FMC00706-6
ActiveFairview Microwave
CBL ASSY SMPPLUG-SMPJACK 6
Description
General part information
FMC00706-6
Cable Assembly Coaxial SMP to SMP Hand Formable .047 6.000" (152.40mm)
Technical Specifications
Parameters and characteristics for this part
| Specification | FMC00706-6 |
|---|---|
| 1st Connector | SMP Jack, Right Angle |
| 1st Connector Mounting Feature | Front Side Nut, Bulkhead |
| 1st Connector Mounting Type | Panel Mount |
| 1st Contact Gender | Female |
| 2nd Connector | SMP Plug |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Male |
| Cable Impedance | 50 Ohms |
| Cable Type | Hand Formable |
| Cable Type Size | 0.047 |
| Connector Impedance | 50 Ohms |
| Frequency - Max | 18 GHz |
| Length | 0.5 ft |
| Overall Impedance | 50 Ohms |
| Style | SMP |
