General part information
14021215101333
12 Position Wire to Board Terminal Block Vertical with Board 0.150" (3.81mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 14021215101333 |
|---|---|
| Color | Black |
| Contact Material | Copper Alloy |
| Current | 10 A |
| Features | Push Button Actuated |
| Housing Material | PPA, PA, Polyphthalamide, Polyamide, Nylon |
| Mating Orientation | Vertical with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 110 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.15 in |
| Plating | Tin Plated |
| Positions Per Level | 12 |
| Voltage | 300 V |
| Wire Gauge (AWG) (Max) | 30 AWG |
| Wire Gauge (AWG) (Min) | 16 AWG |
| Wire Termination | Spring Cage, Screwless, Tension Clamp |
