Description
General part information
PB1000
Bridge Rectifier Single Phase Standard 50 V Through Hole PB
Technical Specifications
Parameters and characteristics for this part
| Specification | PB1000 |
|---|---|
| Current - Average Rectified (Io) | 7 A |
| Current - Reverse Leakage | 5 µA |
| Diode Type | Single Phase |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -50 °C |
| Package / Case | 4-SIP, PB, 4-Square |
| Package Name | PB |
| Technology | Standard |
| Voltage - Forward (Vf) (Max) | 1.2 V |
| Voltage - Peak Reverse (Max) | 50 V |
