Description
General part information
PRC40W-110-S5
Isolated Module DC DC Converter 1 Output 5V 8A 40V - 160V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | PRC40W-110-S5 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, UKCA |
| Current - Output (Max) | 8 A |
| Efficiency | 88.5 % |
| Features | Adjustable Output, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 6-DIP Module |
| Power (Watts) | 40 W |
| Size / Dimension Height | 0.41 in |
| Size / Dimension Length | 2 in |
| Size / Dimension Width | 1 in |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 160 VDC |
| Voltage - Input (Min) | 40 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 5 V |
