6069-410-015
ActiveDigilent, Inc.
DAQ DEVICE MULTIFUNC I/O USB 2.0
6069-410-015
ActiveDigilent, Inc.
DAQ DEVICE MULTIFUNC I/O USB 2.0
Description
General part information
6069-410-015
Multifunction I/O DAQ Device USB 2.0 Screw Terminal
Technical Specifications
Parameters and characteristics for this part
| Specification | 6069-410-015 |
|---|---|
| Bidirectional Channels | 8 |
| Bus Connection | USB 2.0 |
| Counter/Timers | 1 |
| Front Connection | Screw Terminal |
| Function | Multifunction I/O |
| Input Resolution | 16 Bits |
| Input Types | Digital, Analog |
| Input Voltage (Max) | 10 VDC |
| Input Voltage (Min) | -10 V |
| Number of Analog Inputs | 8 |
| Number of Digital Inputs | 8 |
| Number of Outputs | 8 |
| Output Type | Digital |
| Sampling Rate (Per Second) | 100 kHz |
| Type | DAQ Device |
