7683
ActiveKeystone Electronics
WASHER SHOULDER #6 NYLON
7683
ActiveKeystone Electronics
WASHER SHOULDER #6 NYLON
Description
General part information
7683
#6 Shoulder Washer 0.094" (2.39mm) 3/32" Thick Nylon
Technical Specifications
Parameters and characteristics for this part
| Specification | 7683 |
|---|---|
| Diameter - Inside | 0.14 in |
| Diameter - Outside | 0.25 in |
| Diameter - Outside (Nominal) | 0.25 in |
| Diameter - Shoulder | 0.185 in |
| Length - Below Head | 0.032 in |
| Material | Nylon |
| Thickness - Overall | 0.094 in |
| Thread/Screw/Hole Size | #6 |
