8489 0601000

Active

Belden Inc.

CABLE 4COND 18AWG CHROME

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 4COND 18AWG CHROME

Technical Specifications

Parameters and characteristics for this part

Specification	8489 0601000

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	19
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.257 in
Jacket (Insulation) Diameter [diameter]	6.53 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Chrome
Length	1000 ft
Length	304.8 m
Number of Conductors	4
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2598
Usage	Audio, Instrumentation, Control
Voltage	300 V
Wire Gauge	18 AWG

Part	Wire Gauge	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Insulation	Jacket Color	Length [x]	Length [x]	Conductor Material	Cable Type	Usage	Voltage	Ratings	Length	Length
Belden Inc. 8489 060100	18 AWG	Poly-Vinyl Chloride (PVC)	0.257 in	6.53 mm	4	19	30 AWG	-20 C	60 °C	Poly-Vinyl Chloride (PVC)	Chrome	30.5 m	100 ft	Copper Tinned	Multi-Conductor	Audio Control Instrumentation
Belden Inc. 8489 060250	18 AWG	Poly-Vinyl Chloride (PVC)	0.257 in	6.53 mm	4	19	30 AWG	-20 C	60 °C	Poly-Vinyl Chloride (PVC)	Chrome			Copper Tinned	Multi-Conductor	Audio Control Instrumentation	300 V	UL Style 2598	3000 "	76.2 m
Belden Inc. 8489 0601000	18 AWG	Poly-Vinyl Chloride (PVC)	0.257 in	6.53 mm	4	19	30 AWG	-20 C	60 °C	Poly-Vinyl Chloride (PVC)	Chrome			Copper Tinned	Multi-Conductor	Audio Control Instrumentation	300 V	UL Style 2598	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Conductor Multi-Conductor Cable Chrome 18 AWG 1000.0' (304.8m)
