0010011094

Active

Molex

CONN RCPT HSG 9POS 5.08MM

Search across all available documentation for this part.

Active

Molex

CONN RCPT HSG 9POS 5.08MM

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	0010011094	001001 Series

Color	Natural	Natural
Connector Type	Receptacle	Receptacle
Contact Termination	Crimp	Crimp
Contact Type	Non-Gendered	Non-Gendered, Female Socket
Fastening Type	-	Locking Ramp
Insulation Material	Polyamide (PA), Nylon	Polyamide (PA), Nylon, Polyamide (PA66), Nylon 6/6
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Note	Contacts Not Included	Contacts Not Included
Number of Positions	9	9 - 11
Number of Rows	1	1
Operating Temperature	-	-40 °C
Operating Temperature	-	105 ░C
Pitch [x]	0.2 in	0.2 in
Pitch [x]	5.08 mm	5.08 mm

CONN HOUSING RCP 11 POS 5.08MM CRIMP ST CABLE MOUNT NATURAL KK® BAG

Part	Connector Type	Pitch [x]	Pitch [x]	Note	Color	Mounting Type	Contact Type	Number of Rows	Insulation Material	Number of Positions	Contact Termination	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]
Molex 0010011114	Receptacle	0.2 in	5.08 mm	Contacts Not Included	Natural	Free Hanging (In-Line)	Non-Gendered	1	Nylon, Polyamide (PA)	11	Crimp
Molex 0010013056	Receptacle	0.2 in	5.08 mm	Contacts Not Included	Natural	Free Hanging (In-Line)	Female Socket	1	Polyamide (PA66), Nylon 6/6		Crimp	Locking Ramp	-40 °C	105 ░C
Molex 0010011104	Receptacle	0.2 in	5.08 mm	Contacts Not Included	Natural	Free Hanging (In-Line)	Non-Gendered	1	Nylon, Polyamide (PA)	10	Crimp
Molex 0010011094	Receptacle	0.2 in	5.08 mm	Contacts Not Included	Natural	Free Hanging (In-Line)	Non-Gendered	1	Nylon, Polyamide (PA)	9	Crimp

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

9 Rectangular Connectors - Housings Receptacle Natural 0.200" (5.08mm)
