FMAM1060
ActiveFairview Microwave
LOWNOISEAMP 40MHZ-3GHZ P1DB SMA
FMAM1060
ActiveFairview Microwave
LOWNOISEAMP 40MHZ-3GHZ P1DB SMA
Description
General part information
FMAM1060
RF Amplifier IC General Purpose 40MHz ~ 3GHz Module
Technical Specifications
Parameters and characteristics for this part
| Specification | FMAM1060 |
|---|---|
| Current - Supply | 18 mA |
| Frequency (Max) | 3 GHz |
| Frequency (Min) | 40 MHz |
| Gain | 16 dB |
| Mounting Type | Chassis Mount |
| Noise Figure | 1.3 dB |
| P1dB | 7 dBm |
| Package / Case | Module, SMA Connectors |
| Package Name | Module |
| RF Type | General Purpose |
| Voltage - Supply (Maximum) | 3.3 V |
| Voltage - Supply (Minimum) | 2.7 V |
