IPSPD-1-BK-T5-UL

Active

Sure-Seal

CONN PLUG FMALE 1P SILV THREADED

Search across all available documentation for this part.

Active

Sure-Seal

CONN PLUG FMALE 1P SILV THREADED

Technical Specifications

Parameters and characteristics for this part

Specification	IPSPD-1-BK-T5-UL

Applications	Industrial
Color	Black
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Silver
Current Rating (Amps)	800 A
Fastening Type	Bayonet Lock
Ingress Protection	IP67 - Dust Tight, Waterproof
Material Flammability Rating	UL94 V-0
Mounting Feature	Flange
Number of Positions	1
Primary Material	Plastic
Termination	Threaded
Voltage Rating	1000 VAC

CONN PLUG FMALE 1P SILV THREADED

Part	Contact Finish - Mating	Voltage Rating	Material Flammability Rating	Fastening Type	Primary Material	Color	Applications	Connector Type	Termination	Current Rating (Amps)	Number of Positions	Ingress Protection	Mounting Feature
Sure-Seal IPSPD-1-BK-T5-UL	Silver	1000 VAC	UL94 V-0	Bayonet Lock	Plastic	Black	Industrial	Female Sockets, Plug	Threaded	800 A	1	IP67 - Dust Tight, Waterproof	Flange

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1 Position Circular Connector Plug, Female Sockets Threaded
