Description
General part information
787-6716/9300-000
3 Position Circular Connector Receptacle, Female Sockets
Technical Specifications
Parameters and characteristics for this part
| Specification | 787-6716/9300-000 |
|---|---|
| Color | Silver |
| Connector Type | Receptacle, Female Sockets |
| Current Rating | 9 A |
| Fastening Type | Threaded |
| Features | Backshell |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 3 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -25 °C |
| Orientation | Keyed |
| Shell Size - Insert | 7/8"-3 |
| Shielding | Unshielded |
| Voltage Rating | 600 V |
| Voltage Rating (Type) | DC |
