Description
General part information
EXV107M016S9GAA
100 µF 16 V Aluminum Electrolytic Capacitors Radial, Can - SMD 3000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | EXV107M016S9GAA |
|---|---|
| Applications | Automotive |
| Capacitance | 100 µF |
| Height - Seated (Max) | 0.222 in |
| Lifetime | 3000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current | 168 mA, 240 mA |
| Size / Dimension Diameter | 0.248 in |
| Surface Mount Land Length | 0.26 in |
| Surface Mount Land Width | 0.26 in |
| Tolerance | 20 % |
| Voltage - Rated | 16 V |
