Description
General part information
3132CR188
5/16"-18 Round Head Carriage Bolt Drive Stainless Steel
Technical Specifications
Parameters and characteristics for this part
| Specification | 3132CR188 |
|---|---|
| Features | Standard |
| Head Diameter | 0.704 in |
| Head Height | 0.166 in |
| Length - Below Head | 2 in |
| Length - Overall | 2.166 in |
| Material | Stainless Steel |
| Plating | Plain |
| Screw Head Type | Round Head |
| Thread Pitch (TPI) | 18 TPI |
| Thread Size (Nominal) | 0.3125 in |
| Type | Carriage Bolt |
