LED25W-12-C2080

Active

Thomas Research Products

LED DRIVER CC AC/DC 4-12V 2.08A

Search across all available documentation for this part.

Active

Thomas Research Products

LED DRIVER CC AC/DC 4-12V 2.08A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	500	$ 30.99

General part information

2.08A 6 ~ 12V Constant Current LED Driver AC DC Converter Topology 1 Output

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	LED25W-12-C2080	LED25W Series

Approval Agency	CE, cURus	CE, cURus, cULus, CE
Current - Output (Max) [Max]	2.08 A	1.04 - 620 A
Efficiency	81 %	81 - 84 %
Features	SCP, OCP, OVP	SCP, OCP, OVP
Mounting Type	Chassis Mount	Chassis Mount
Number of Outputs	1	1
Power (Watts)	25 W	25 W
Ratings	IP66	IP66
Size / Dimension	-	80 mm
Size / Dimension	-	78 mm
Size / Dimension	-	25.2 mm
Size / Dimension [x]	80 mm	3.15 - 80 mm
Size / Dimension [x]	3.15 in	3.15 in
Size / Dimension [y]	62 mm	3.07 - 62 mm
Size / Dimension [y]	2.44 "	2.44 "
Size / Dimension [z]	0.99 "	0.99 "
Size / Dimension [z]	25.2 mm	0.99 - 25.2 mm
Termination Style	Wire Leads	Wire Leads
Topology	AC DC Converter	AC DC Converter
Type	Constant Current	Constant Current, Constant Voltage
Voltage - Input (Max) [Max]	305 VAC	305 VAC
Voltage - Input (Min) [Min]	90 VAC	90 VAC
Voltage - Output	-	24 V
Voltage - Output [Max]	12 V	12 - 36 V
Voltage - Output [Min]	6 V	6 - 12 V
Weight	198 g	198 g
Weight	0.437 lb	0.437 lb

LED DRIVER CC AC/DC 4-12V 2.08A

Part	Current - Output (Max) [Max]	Mounting Type	Efficiency	Approval Agency	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Features	Number of Outputs	Topology	Voltage - Input (Min) [Min]	Voltage - Output [Min]	Voltage - Output [Max]	Power (Watts)	Ratings	Type	Voltage - Input (Max) [Max]	Weight	Weight	Termination Style	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Output
Thomas Research Products LED25W-12-C2080	2.08 A	Chassis Mount	81 %	CE, cURus	62 mm	2.44 "	80 mm	3.15 in	0.99 "	25.2 mm	OCP, OVP, SCP	1	AC DC Converter	90 VAC	6 V	12 V	25 W	IP66	Constant Current	305 VAC	198 g	0.437 lb	Wire Leads
Thomas Research Products LED25W-36-C0620	620 mA	Chassis Mount	84 %	CE, cULus	3.07 "		3.15 in			0.99 in	OCP, OVP, SCP	1	AC DC Converter	90 VAC	12 V	36 V	25 W	IP66	Constant Current	305 VAC	198 g	0.437 lb	Wire Leads	80 mm	78 mm	25.2 mm
Thomas Research Products LED25W-24	1.04 A	Chassis Mount	83 %	CE, cULus	3.07 "		3.15 in			0.99 in	OCP, OVP, SCP	1	AC DC Converter	90 VAC			25 W	IP66	Constant Voltage	305 VAC	198 g	0.437 lb	Wire Leads	80 mm	78 mm	25.2 mm	24 V
