NDH2412SC

Active

Murata Power Solutions Inc.

DC DC CONVERTER +/-12V 3W

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

DC DC CONVERTER +/-12V 3W

Technical Specifications

Parameters and characteristics commom to parts in this series

DC DC CONVERTER +/-12V 3W

Part	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Package / Case	Mounting Type	Number of Outputs	Voltage - Input (Min) [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Current - Output (Max)	Current - Output (Max)	Voltage - Input (Max) [Max]	Applications	Power (Watts)	Type	Voltage - Output 1	Voltage - Isolation	Voltage - Output 2	Current - Output (Max)
Murata Power Solutions Inc. NDH2412SC	85 °C	-40 °C	81 %	9-SIP Module, 7 Leads	Through Hole	2	18 V	0.49 in	1.02 in	12.4 mm	0.36 in	25.9 mm	9.1 mm	125 mA	125 mA	36 V	ITE (Commercial)	3 W	Isolated Module	12 V	1000 V	-12 V
Murata Power Solutions Inc. NDH2415SC	85 °C	-40 °C		9-SIP Module, 7 Leads	Through Hole	2	18 V	0.49 in	1.02 in	12.4 mm	0.36 in	25.9 mm	9.1 mm	100 mA		36 V	ITE (Commercial)	3 W	Isolated Module	15 V	1000 V	-15 V	100 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 2 Output 12V -12V 125mA, 125mA 18V - 36V Input
