Specification	0029110043

Color	Ivory
Connector Type	Plug
Contact Termination	Crimp
Contact Type	Male Pin
Fastening Type	Friction Lock
Insulation Material	Polyamide (PA66), Nylon 6/6
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	4
Number of Rows	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch	0.098 in

002911 Series

Part	Note	Fastening Type	Color	Number of Positions	Number of Rows	Insulation Material	Pitch	Mounting Type	Contact Type	Connector Type	Contact Termination	Operating Temperature (Min)	Operating Temperature (Max)
Molex 0029110052	Contacts Not Included	Eject Hooks Latch Lock	Ivory	5	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Panel Mount	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110033	Contacts Not Included	Friction Lock	Ivory	3	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Free Hanging (In-Line)	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110082	Contacts Not Included	Eject Hooks Latch Lock	Ivory	8	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Panel Mount	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110053	Contacts Not Included	Friction Lock	Ivory	5	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Free Hanging (In-Line)	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110143		Push-Pull	White	14	1	Nylon 6/6 Polyamide (PA66)	0.098 in		Male Pin	Plug	Crimp
Molex 0029110022	Contacts Not Included	Eject Hooks Latch Lock	Ivory	2	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Panel Mount	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110112	Contacts Not Included	Eject Hooks Latch Lock	Ivory	11	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Panel Mount	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110122	Contacts Not Included	Eject Hooks Latch Lock	Ivory	12	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Panel Mount	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110023	Contacts Not Included	Friction Lock	Ivory	2	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Free Hanging (In-Line)	Male Pin	Plug	Crimp	-40 °C	105 °C
Molex 0029110073	Contacts Not Included	Friction Lock	Ivory	7	1	Nylon 6/6 Polyamide (PA66)	0.098 in	Free Hanging (In-Line)	Male Pin	Plug	Crimp	-40 °C	105 °C
