52000

Active

Murrelektronik, Inc

MIRO 6,2-1OUTPUT-REL.24VDC-1U, M

Search across all available documentation for this part.

Active

Murrelektronik, Inc

MIRO 6,2-1OUTPUT-REL.24VDC-1U, M

Technical Specifications

Parameters and characteristics for this part

MIRO 6,2-1OUTPUT-REL.24VDC-1U, M

Part	Coil Voltage	Features	Termination Style	Operate Time	Approval Agency	Contact Rating (Current)	Relay Type	Release Time	Load - Max Switching	Coil Type	Switching Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Contact Form	Contact Material
Murrelektronik, Inc 52000	24 VDC	LED Indicator	Screw Terminal	10 ms	CCC, CE, CSA, cURus	6 A	General Purpose	15 ms	144 W, 1500 VA	Non Latching	250 VAC, 250 VDC	-25 °C	60 °C	DIN Rail	DPST-NO/NC	Silver Tin Oxide (AgSnO)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay DPST-NO/NC (1 Form A, 1 Form B) 24VDC Coil DIN Rail

Technical documentation and resources

No documents available
