Description
General part information
EG95JPGA-128-SGNS
Cellular GPRS, HSPA+, LTE, UMTS, WCDMA Transceiver Module Antenna Not Included Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | EG95JPGA-128-SGNS |
|---|---|
| Antenna Type | Antenna Not Included |
| Data Rate | 150 MHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -35 °C |
| Package / Case | 106-BLGA Module |
| Protocol | UMTS, HSPA+, LTE, WCDMA, GPRS |
| RF Family/Standard | Cellular |
| Serial Interfaces | ADC, GPIO, PCM, UART, USB |
| Utilized IC / Part | MDM9307-0 |
| Voltage - Supply (Maximum) | 4.3 V |
| Voltage - Supply (Minimum) | 3.3 V |
