MPE-15SV-05
ActiveMicroPower Direct
AC-DC 85-305VAC 5VOUT 15W ENCLOS
MPE-15SV-05
ActiveMicroPower Direct
AC-DC 85-305VAC 5VOUT 15W ENCLOS
Description
General part information
MPE-15SV-05
Enclosed AC DC Converters 1 Output 5V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | MPE-15SV-05 |
|---|---|
| Applications | Industrial |
| Approval Agency | CE, UL, UKCA |
| Efficiency | 78 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -30 °C |
| Power (Watts) | 15 W |
| Size / Dimension Height | 0.98 in |
| Size / Dimension Length | 3.07 in |
| Size / Dimension Width | 2.17 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
