944L101K102ABI
ActiveCornell Dubilier Knowles
DC LINK, LOW INDUCTANCE
944L101K102ABI
ActiveCornell Dubilier Knowles
DC LINK, LOW INDUCTANCE
Description
General part information
944L101K102ABI
100 µF Film Capacitor 230V 1000V (1kV) Polypropylene (PP), Metallized Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | 944L101K102ABI |
|---|---|
| Applications | DC Filtering, DC Link |
| Capacitance | 100 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 0.7 mOhm |
| Features | Low ESL, Low ESR |
| Height - Seated (Max) | 2.028 in |
| Lead Spacing | 1.772 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 3.327 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - AC | 230 V |
| Voltage Rating - DC | 1 kV |
