| Color | Gray | White, Gray, Brown, Black, Blue, Purple, Yellow, Green, Red, Transparent, Orange |
| Current - IEC | 24 A | 6.3 - 415 A |
| Current - UL | 22 A | 10 - 230 A |
| Disconnect Type | - | Switch, Knife, Fuse, Lever, Open, Component, Removable Plug |
| Features | - | Interlocking (Side), LED Indicator, Diode |
| For Use With/Related Products | - | SNK Series, SNK Series Test Plugs, SNK, ZK, SNK, ZS Series, ZS Series, SNK, SNK, ZK Series, 5.2mm Wide Terminal Blocks, ZDS, RGW, ZDK, ZDP, ZK Series, 16mm Wide Terminal Blocks, Ferrules, ZK, ZP, ZDK Series, SNK, ZDS Series |
| Fuse Type | - | 20 - 32 mm |
| Fuse Type | - | 5 - 6.3 mm |
| Fuse Type | - | 5mm x 25mm, 5mm x 20mm |
| Height (Max) | - | 1.98 - 2.72 in |
| Height (Max) | - | 50.29 - 69.1 mm |
| Height (Max) | - | 50.55 mm |
| Housing Color | - | Gray, Green, Yellow, Blue |
| Housing Material | Polyamide (PA), Nylon | Polyamide (PA), Nylon |
| Insulation Height | 36.32 mm | 36.32 mm |
| Insulation Height | 1.43 in | 1.43 in |
| Insulation Height | - | 39.37 mm |
| Insulation Height | - | 1.55 in |
| Legend | - | Letters, O, Letters, S, L2, L1, W1, W, Letters, G, Letters, K, Numbers, 1 through 100, Numbers, 1 through 10, 101 through 110, V2, U1, Letters, I, Numbers, 5, Letters, N, Numbers, 9, W3, Blank, U2, Letters, M, Ground Symbol, Numbers, 51 through 60, Numbers, 101 through 200, Symbol, ~, Letters, A, Letters, E, Letters, U, Letters, Q, 11 through 20, U3, L3, 21 through 30, Numbers, 2, Numbers, 3, Letters, R, Letters, J, 201 through 300, Letters, F, Letters, X, +24V, N, PE, 401 through 500, Letters, L, Numbers, 301 through 400, Numbers, 0, Letters, H, 151 through 160, Letters, D, W2, V1, V3, Letters, P, -, Letters, Z, +48V, Numbers, 121 through 130, Letters, B, Numbers, 0 through 9, Numbers, 801 through 900, Letters, T, Symbol, =, Numbers, 6, Numbers, 4, 81 through 90, Letters, Y |
| Legend | - | 40 - 1000 |
| Legend | - | 31 - 901 |
| Legend | - | -48 - 8 V |
| Length | - | 3.46 - 3.69 in |
| Length | - | 80.26 - 93.73 mm |
| Length | - | 81.03 - 107.95 mm |
| Length | - | 3.16 - 4.25 in |
| Length - Overall | - | 1.97 - 5.9 in |
| Length - Overall | - | 50 - 150 mm |
| Material - Insulation | - | Nylon, Polyamide (PA) |
| Material Flammability Rating | - | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line), DIN Rail |
| Number of Levels | 1 | 1 - 2 |
| Number of Levels | - | Connected, 1 Grounded |
| Number of Positions | 10 | 1 - 50 |
| Operating Temperature [Max] | 110 °C | 110 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Pitch | - | 0.205 - 1.024 in |
| Pitch | - | 5.2 - 26 mm |
| Positions Per Level | 10 | 1 - 12 |
| Ratcheting | - | Ratchet |
| Stripping Length | - | 10 - 38 mm |
| Stripping Length | - | 12 mm |
| Style | - | Flat Pins, Screw - Full Thread, Screw In |
| Terminal - Width | - | 5.2 - 26 mm |
| Terminal - Width | - | 22 mm |
| Terminal - Width | - | 32 - 36 mm |
| Termination Style | Screwless - Spring Cage, Tension Clamp | Push In, Spring, Screw, Screwless - Spring Cage, Tension Clamp, Screw - Rising Cage Clamp, Plug Receptacles |
| Tip Type | - | Slotted |
| Tool Type | - | Screwdriver, Hand Crimper |
| Type | Plug, Female Sockets | Snap In, Label, Feed Through, Disconnect, Plug, Female Sockets, Marker Holder, Test Plug Adapter, Terminal Block, Cross Connection, Shield Connector, Ground, Earth, Terminal Block, DIN Rail, End Plate, Plug Connection, Separator, Rail Type, Test Plug, Cover, End Stop, Earth/Neutral, Ground, Component Plug, Spacer, Label, Adhesive |
| Voltage - IEC | 1 kV | 1 - 800 kV |
| Voltage - UL | - | 300 - 1000 V |
| Voltage - UL | - | 150 - 300 V |
| Wire Entry Location | - | Side Entry |
| Wire Gauge or Range - AWG | - | 2/0 |
| Wire Gauge or Range - AWG | - | 0 - 500 AWG |
| Wire Gauge or Range - AWG [Max] | 26 AWG | 2 - 28 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG | 0 - 12 AWG |
| Wire Gauge or Range - mm˛ | - | 0.2 - 6 mm˛ |
| Wire Gauge or Range - mm˛ | - | 4 - 300 mm˛ |
| Wire Gauge or Range - mm² [Max] | 4 mm² | 4 - 120 mm² |
| Wire Gauge or Range - mm² [Min] | 0.2 mm² | 0.2 - 35 mm² |
| Wire Strip Length | 11 mm | 10.5 - 12.5 mm |
