AM2D-2415DH40Z
Activeaimtec
DC DC CONVERTER +/-15V 2W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM2D-2415DH40Z
Activeaimtec
DC DC CONVERTER +/-15V 2W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM2D-2415DH40Z |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output (Max) | 67 mA |
| Current - Output (Max) | 67 mA |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 0.76 " |
| Size / Dimension [x] | 19.5 mm |
| Size / Dimension [y] | 6 mm |
| Size / Dimension [y] | 0.24 " |
| Size / Dimension [z] | 0.39 in |
| Size / Dimension [z] | 10 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 26.4 V |
| Voltage - Input (Min) [Min] | 21.6 V |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 [Max] | 15 V |
| Voltage - Output 1 [Min] | -15 V |
| Voltage - Output 2 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 9.71 | |
| 5 | $ 9.52 | |||
| 10 | $ 9.32 | |||
| 15 | $ 9.14 | |||
| 25 | $ 8.96 | |||
| 50 | $ 8.78 | |||
| 100 | $ 8.60 | |||
| 230 | $ 8.43 | |||
| 440 | $ 8.26 | |||
Description
General part information
AM2D-2415DH40Z
Isolated Module DC DC Converter 2 Output -15 ~ 15V -15V 67mA, 67mA 21.6V - 26.4V Input
