PMCE-0056
ActivePremier Magnetics
CMC 5.6MH 2.25A 2LN THROUGH HOLE
PMCE-0056
ActivePremier Magnetics
CMC 5.6MH 2.25A 2LN THROUGH HOLE
Description
General part information
PMCE-0056
5.6 mH @ 1 kHz 2 Line Common Mode Choke Through Hole 2.25A DCR 80mOhm
Technical Specifications
Parameters and characteristics for this part
| Specification | PMCE-0056 |
|---|---|
| Current Rating (Max) | 2.25 A |
| DC Resistance (DCR) (Max) | 80 mOhm |
| Filter Type | Power Line |
| Height (Max) | 1.063 in |
| Inductance | 5.6 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Size / Dimension Length | 0.826 in |
| Size / Dimension Width | 0.75 in |
| Voltage Rating - AC | 3750 V |
