CN30A110-12
ActiveTDK-LAMBDA
ISOLATED THROUGH HOLE DC/DC CONVERTER, QUARTER BRICK, 30 W, 1 OUTPUT, 12 V
Deep-Dive with AI
Search across all available documentation for this part.
CN30A110-12
ActiveTDK-LAMBDA
ISOLATED THROUGH HOLE DC/DC CONVERTER, QUARTER BRICK, 30 W, 1 OUTPUT, 12 V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CN30A110-12 |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 2.5 A |
| Efficiency | 84 % |
| Features | Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 1/4 Brick, 8-DIP Module |
| Power (Watts) | 30 W |
| Size / Dimension [x] | 57.9 mm |
| Size / Dimension [x] | 2.28 in |
| Size / Dimension [y] | 1.45 in |
| Size / Dimension [y] | 36.8 mm |
| Size / Dimension [z] | 12.7 mm |
| Size / Dimension [z] | 0.5 in |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 160 V |
| Voltage - Input (Min) [Min] | 60 V |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
CN30A110-12
Isolated Module DC DC Converter 1 Output 12V 2.5A 60V - 160V Input
