Part	Contact Finish	Termination	Flat Flex Type	Actuator Material	Housing Material	FFC, FCB Thickness	Features	Pitch	Locking Feature	Height Above Board	Material Flammability Rating	Mounting Type	Cable End Type	Operating Temperature (Min)	Operating Temperature (Max)	Number of Positions	Connector/Contact Type	Contact Material	Housing Color	Actuator Color	Contact Finish Thickness	Voltage Rating	Mating Cycles	Current Rating
Hirose Electric Co Ltd FH28E-50S-0.5SH(05)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	50	Bottom Contacts	Phosphor Bronze	Gray	Black	2 µin
Hirose Electric Co Ltd FH28D-20S-0.5SH(05)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	20	Bottom Contacts	Phosphor Bronze	Gray	Black		50 V	20 cycles	0.5 A
Hirose Electric Co Ltd FH28E-20S-0.5SH(05)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	20	Bottom Contacts	Phosphor Bronze
Hirose Electric Co Ltd FH28E-50S-0.5SH(98)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	50	Bottom Contacts	Phosphor Bronze	Gray	Black
Hirose Electric Co Ltd FH28D-50S-0.5SH(98)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	50	Bottom Contacts	Phosphor Bronze				50 V
Hirose Electric Co Ltd FH28-10S-0.5SH(05)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	10	Bottom Contacts	Phosphor Bronze	Gray	Black		50 V	20 cycles	0.5 A
Hirose Electric Co Ltd FH28E-40S-0.5SH(07)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	40	Bottom Contacts	Phosphor Bronze	Gray	Black
Hirose Electric Co Ltd FH28D-74S-0.5SH(98)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	74	Bottom Contacts	Phosphor Bronze	Gray	Black		50 V	20 cycles	0.5 A
Hirose Electric Co Ltd FH28D-50S-0.5SH(05)	Gold	Solder	FFC FPC	Halogen Free Liquid Crystal Polymer (LCP)	Halogen Free LCP Liquid Crystal Polymer	0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in	UL94 V-0	Right Angle Surface Mount	Tabbed	-40 °C	105 °C	50	Bottom Contacts	Phosphor Bronze	Gray	Black		50 V	20 cycles	0.5 A
Hirose Electric Co Ltd FH28D-68S-0.5SH(39)		Solder	FFC FPC			0.3 mm	Solder Retention Zero Insertion Force (ZIF)	0.02 in	Rotary Lock	0.1 in		Right Angle Surface Mount	Tabbed	-40 °C	105 °C	68	Bottom Contacts	Phosphor Bronze				50 V		0.5 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

FH28B-40S-0.5SH(98) | Datasheet
