CDBQR00340

Active

Comchip Technology

DIODE SCHOTTKY 40V 30MA 0402

Search across all available documentation for this part.

Active

Comchip Technology

DIODE SCHOTTKY 40V 30MA 0402

Technical Specifications

Parameters and characteristics for this part

Specification	CDBQR00340

Capacitance @ Vr, F	1.5 pF
Current - Average Rectified (Io)	30 mA
Current - Reverse Leakage @ Vr	1 µA
Mounting Type	Surface Mount
Operating Temperature - Junction	125 °C
Package / Case	0402 (1006 Metric)
Speed	Any Speed
Speed	200 mA
Supplier Device Package	0402
Supplier Device Package	SOD-923F
Technology	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	40 V
Voltage - Forward (Vf) (Max) @ If	370 mV

DIODE SCHOTTKY 40V 30MA 0402

Part	Speed	Speed	Operating Temperature - Junction	Package / Case	Mounting Type	Voltage - Forward (Vf) (Max) @ If	Supplier Device Package	Supplier Device Package	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max) [Max]	Current - Average Rectified (Io)	Technology	Capacitance @ Vr, F
Comchip Technology CDBQR00340	Any Speed	200 mA	125 °C	0402 (1006 Metric)	Surface Mount	370 mV	0402	SOD-923F	1 µA	40 V	30 mA	Schottky	1.5 pF

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Diode 40 V 30mA Surface Mount 0402/SOD-923F

Technical documentation and resources

No documents available
