2316-6121-TP

Active

CONN HEADER VERT 16POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

2316-6121-TP

Active

CONN HEADER VERT 16POS 2.54MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	2316-6121-TP	2316 Series

Connector Type	Header	Header
Contact Finish - Mating	Tin-Lead	Tin-Lead, Gold
Contact Finish - Post	Tin-Lead	Tin-Lead
Contact Finish Thickness - Mating	-	10 çin
Contact Finish Thickness - Mating	-	0.25 çm
Contact Finish Thickness - Post	2.54 µm	2.54 µm
Contact Finish Thickness - Post	100 µin	100 µin
Contact Length - Mating	5.84 mm	5.84 mm
Contact Length - Mating	-	8.08 mm
Contact Length - Mating [x]	0.23 in	0.23 - 0.318 in
Contact Length - Post [x]	0.12 in	0.12 in
Contact Length - Post [x]	3.05 mm	3.05 mm
Contact Material	Copper Alloy	Copper Alloy
Contact Shape	Square	Square
Contact Type	Male Pin	Male Pin
Current Rating (Amps)	3 A	3 A
Fastening Type	Push-Pull	Push-Pull
Insulation Color	Black	Black
Insulation Height	0.1 in	0.1 in
Insulation Height	2.54 mm	2.54 mm
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Through Hole	Through Hole
Number of Positions	16	16
Number of Positions Loaded	All	All
Number of Rows	2	1 - 2
Operating Temperature [Max]	105 ░C	105 ░C
Operating Temperature [Min]	-55 °C	-55 °C
Overall Contact Length	0.45 "	0.45 - 0.538 "
Overall Contact Length	11.43 mm	11.43 - 13.67 mm
Pitch - Mating	0.1 in	0.1 in
Pitch - Mating	2.54 mm	2.54 mm
Row Spacing - Mating [x]	2.54 mm	2.54 mm
Row Spacing - Mating [x]	0.1 in	0.1 in
Shrouding	Unshrouded	Unshrouded
Style	Board to Board, Cable	Board to Board, Cable
Termination	Solder	Solder

2316 Series

CONN HEADER VERT 16POS 2.54MM

Part	Termination	Number of Rows	Insulation Height	Insulation Height	Contact Length - Post [x]	Contact Length - Post [x]	Mounting Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Shape	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Fastening Type	Material Flammability Rating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Shrouding	Overall Contact Length	Overall Contact Length	Contact Length - Mating [x]	Contact Length - Mating	Style	Insulation Color	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish - Mating	Contact Type	Connector Type	Contact Material	Number of Positions	Current Rating (Amps)	Number of Positions Loaded	Contact Length - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating
3M 2316-6121-TP	Solder	2	0.1 in	2.54 mm	0.12 in	3.05 mm	Through Hole	2.54 µm	100 µin	Square	Tin-Lead	0.1 in	2.54 mm	Push-Pull	UL94 V-0	2.54 mm	0.1 in	Unshrouded	0.45 "	11.43 mm	0.23 in	5.84 mm	Board to Board, Cable	Black	105 ░C	-55 °C	Tin-Lead	Male Pin	Header	Copper Alloy	16	3 A	All
3M 2316-6211-TG	Solder	1	0.1 in	2.54 mm	0.12 in	3.05 mm	Through Hole	2.54 µm	100 µin	Square	Tin-Lead	0.1 in	2.54 mm	Push-Pull	UL94 V-0			Unshrouded	0.538 "	13.67 mm	0.318 "		Board to Board, Cable	Black	105 ░C	-55 °C	Gold	Male Pin	Header	Copper Alloy	16	3 A	All	8.08 mm	10 çin	0.25 çm
3M 2316-6121-TG	Solder	2	0.1 in	2.54 mm	0.12 in	3.05 mm	Through Hole	2.54 µm	100 µin	Square	Tin-Lead	0.1 in	2.54 mm	Push-Pull	UL94 V-0	2.54 mm	0.1 in	Unshrouded	0.45 "	11.43 mm	0.23 in	5.84 mm	Board to Board, Cable	Black	105 ░C	-55 °C	Gold	Male Pin	Header	Copper Alloy	16	3 A	All		10 çin	0.25 çm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

2316 Series

Connector Header Through Hole 16 position 0.100" (2.54mm)

Documents

Technical documentation and resources
