SS30-E

Active

Sanyo

IC FOR NOTEBOOK PC FAN MOTOR DRI

Search across all available documentation for this part.

Active

Sanyo

IC FOR NOTEBOOK PC FAN MOTOR DRI

Technical Specifications

Parameters and characteristics for this part

Specification	SS30-E

Applications	Fan Motor Driver
Current - Output	700 mA
Function	Driver - Fully Integrated, Control and Power Stage
Interface	PWM
Motor Type - AC, DC	Brushless DC (BLDC)
Mounting Type	Surface Mount
Operating Temperature [Max]	95 °C
Operating Temperature [Min]	-30 °C
Output Configuration	Half Bridge (3)
Package / Case	20-WFQFN
Supplier Device Package	20-VCT (3x3)
Technology	Bi-CMOS
Voltage - Load [Max]	6 V
Voltage - Load [Min]	2.2 V
Voltage - Supply [Max]	6 V
Voltage - Supply [Min]	2.2 V

Part	Function	Applications	Voltage - Supply [Max]	Voltage - Supply [Min]	Motor Type - AC, DC	Interface	Technology	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output	Supplier Device Package	Voltage - Load [Max]	Voltage - Load [Min]	Output Configuration	Mounting Type
Sanyo SS30-E	Driver - Fully Integrated Control and Power Stage	Fan Motor Driver	6 V	2.2 V	Brushless DC (BLDC)	PWM	Bi-CMOS	20-WFQFN	95 °C	-30 °C	700 mA	20-VCT (3x3)	6 V	2.2 V	Half Bridge (3)	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	207	$ 1.46

General part information

Motor Driver Bi-CMOS PWM 20-VCT (3x3)

Technical documentation and resources

No documents available
