1731235
ActivePhoenix Contact
TERM BLOCK PLUG 2POS STR 3.81MM
1731235
ActivePhoenix Contact
TERM BLOCK PLUG 2POS STR 3.81MM
Description
General part information
1731235
2 Position Terminal Block Plug, Female Sockets 0.150" (3.81mm) 180° Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1731235 |
|---|---|
| Contact Mating Finish | Tin |
| Current - IEC | 6 A |
| Insulation Height | 0.508 in |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Pitch | 0.15 in |
| Plug Wire Entry Angle | 180 ° |
| Positions Per Level | 2 |
| Termination Style | IDC |
| Type | Female Sockets, Plug |
| Voltage - IEC | 400 V |
| Wire Gauge or Range - AWG (Max) | 24 AWG |
| Wire Gauge or Range - AWG (Min) | 20 AWG |
| Wire Gauge or Range - mm² (Maximum) | 0.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.34 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
