DFA200AA80
ActiveSanRex Corporation
DIODE MODULE 800V 200A
DFA200AA80
ActiveSanRex Corporation
DIODE MODULE 800V 200A
Description
General part information
DFA200AA80
SCR Module 800 V Bridge, 3-Phase - SCRs/Diodes Chassis Mount Module
Technical Specifications
Parameters and characteristics for this part
| Specification | DFA200AA80 |
|---|---|
| Current - Gate Trigger (Igt) (Max) | 100 mA |
| Current - Non Rep. Surge (Itsm) | 2000 A, 1850 A |
| Current - Non Rep. Surge Frequencies | 50Hz, 60Hz |
| Current - Non Rep. Surge Type | Itsm |
| Current - On State (Max) | 200 A |
| Mounting Type | Chassis Mount |
| Number of Diodes | 6 count |
| Number of SCRs | 1 count |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -30 °C |
| Package / Case | Module |
| Structure | Bridge, 3-Phase - SCRs/Diodes |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Voltage - Off State | 800 V |
