1521H-49.152K18DTSK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
2016HCMOS, 49.152MHZ, 1.8V, 25
1521H-49.152K18DTSK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
2016HCMOS, 49.152MHZ, 1.8V, 25
Description
General part information
1521H-49.152K18DTSK
Oscillator
Technical Specifications
Parameters and characteristics for this part
| Specification | 1521H-49.152K18DTSK |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Max) | 10 mA |
| Frequency | 49.152 MHz |
| Frequency Stability | 15 ppm, 25 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.03 in, 0.018 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | HCMOS |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension Length | 0.079 in |
| Size / Dimension Width | 0.063 in |
| Type | XO (Standard) |
| Voltage - Supply | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
