10560CS
ActiveCentury Spring Corp
COMP O= .593,L= 3.50,W= .100
10560CS
ActiveCentury Spring Corp
COMP O= .593,L= 3.50,W= .100
Description
General part information
10560CS
COMP O= .593,L= 3.50,W= .100
Technical Specifications
Parameters and characteristics for this part
| Specification | 10560CS |
|---|---|
| Diameter - Inside | 0.393 in |
| Diameter - Outside | 0.593 in |
| End Style | Ground, Closed |
| Finish | Zinc |
| Free Length | 3.5 in |
| Material | Spring Steel |
| Rate (lbs/in) | 58 lbs/in |
| Type | Compression |
| Wire Diameter | 0.1 in |
