3076028
ActivePhoenix Contact
TERM BLK BUS BAR 5POS 5.2MM GRAY
3076028
ActivePhoenix Contact
TERM BLK BUS BAR 5POS 5.2MM GRAY
Description
General part information
3076028
5 Position Terminal Block Gray Bus Bar - Side 5.2mm
Technical Specifications
Parameters and characteristics for this part
| Specification | 3076028 |
|---|---|
| Current - IEC | 30 A |
| Current - UL | 20 A |
| Grounded Levels | 1 |
| Height (Max) | 2.323 in |
| Housing Color | Gray |
| Length | 3.68 in |
| Material - Insulation | Polyamide, PA, Nylon |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | DIN Rail |
| Number of Levels | 3 |
| Number of Positions | 5 |
| Stripping Length | 9 mm |
| Terminal Width | 5.2 mm |
| Termination Style | Special, Hybrid |
| Type | Bus Bar - Side |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG (Max) | 25.5 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
| Wire Gauge or Range - mm² (Maximum) | 4 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.2 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
