OD8025-12MBIP68

Active

Orion Fans

DC AXIAL FAN, 12 V, SQUARE, 80 MM, 25 MM, BALL BEARING, 32 CFM

Search across all available documentation for this part.

Active

Orion Fans

DC AXIAL FAN, 12 V, SQUARE, 80 MM, 25 MM, BALL BEARING, 32 CFM

Technical Specifications

Parameters and characteristics for this part

Specification	OD8025-12MBIP68

Air Flow	32 CFM
Air Flow	0.896 m³/min
Approval Agency	cURus, TUV
Bearing Type	Ball
Current Rating (Amps)	150 mA
Fan Type	Tubeaxial
Features	Auto Restart
Ingress Protection	IP68 - Dust Tight, Waterproof
Lifetime @ Temp.	65000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	28 dB
Operating Temperature [Max]	65 °C
Operating Temperature [Max]	65 °C
Operating Temperature [Min]	-15 °C
Operating Temperature [Min]	-15 °C
Power (Watts)	1.8 W
RPM	2700 RPM
Size / Dimension [x]	80 mm
Size / Dimension [y]	80 mm
Termination	2 Wire Leads
Voltage - Rated	12 VDC
Weight	86.64 g
Weight	0.191 lb
Width [y]	25 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	500	$ 12.99
Newark	Each	1	$ 20.10
		1000	$ 18.43

General part information

Fan Tubeaxial 12VDC Square - 80mm L x 80mm H Ball 32.0 CFM (0.896m³/min) 2 Wire Leads
