1-967240-1
ActiveTE Connectivity AMP Connectors
CONN RCPT HSG 10POS 5.00MM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1-967240-1
ActiveTE Connectivity AMP Connectors
CONN RCPT HSG 10POS 5.00MM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-967240-1 |
|---|---|
| Color | Black |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Features | Sealed |
| Insulation Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 5 mm |
| Pitch [x] | 0.197 in |
| Row Spacing [Max] | 0.236 in |
| Row Spacing [Max] | 6 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 2.91 | |
| 10 | $ 2.41 | |||
| 25 | $ 2.24 | |||
| 50 | $ 2.15 | |||
967240 Series
CONN RCPT HSG 10POS 5.00MM
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Connector Type | Note | Pitch [x] | Pitch [x] | Number of Positions | Number of Rows | Color | Row Spacing [Max] | Row Spacing [Max] | Insulation Material | Contact Termination | Features | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors 1-967240-1 | 85 °C | -40 °C | Female Socket | Receptacle | Contacts Not Included | 5 mm | 0.197 in | 10 | 2 | Black | 0.236 in | 6 mm | Polybutylene Terephthalate (PBT), Glass Filled | Crimp | Sealed | Free Hanging (In-Line) |
Description
General part information
967240 Series
10 Rectangular Connectors - Housings Receptacle Black 0.197" (5.00mm)
