Specification	MLP331M420EB0A

Applications	General Purpose
Capacitance	330 µF
ESR (Equivalent Series Resistance)	530 mOhm
Height - Seated (Max)	12.7 mm
Lead Spacing	1 in
Lifetime	2000 Hrs
Mounting Type	Chassis Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Tabbed, FlatPack
Size / Dimension Length	3 in
Size / Dimension Width	1.75 in
Tolerance	20 %
Voltage - Rated	420 V
