9899 009500

Active

Belden Inc.

TEST LEAD 18AWG 5000V WHITE

Search across all available documentation for this part.

Active

Belden Inc.

TEST LEAD 18AWG 5000V WHITE

Technical Specifications

Parameters and characteristics for this part

Specification	9899 009500

Conductor Material	Copper, Tinned
Conductor Strand [custom]	65
Conductor Strand [custom]	36
Jacket (Insulation) Diameter [diameter]	0.144 in
Jacket (Insulation) Diameter [diameter]	3.66 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.048 in
Jacket (Insulation) Thickness	1.22 mm
Length [x]	500 '
Length [x]	152.4 m
Ratings	UL Style 1855
Voltage	5 kVDC
Wire Gauge	18 AWG

Part	Ratings	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Length [x]	Length [x]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Material	Jacket (Insulation) Material	Voltage
Belden Inc. 9899 010500	UL Style 1855	18 AWG	0.048 in	1.22 mm	Black	500 '	152.4 m	0.144 in	3.66 mm	65	36	Copper Tinned	Poly-Vinyl Chloride (PVC)	5 kVDC
Belden Inc. 9899 010100	UL Style 1855	18 AWG	0.048 in	1.22 mm	Black	100 ft	30.5 m	0.144 in	3.66 mm	65	36	Copper Tinned	Poly-Vinyl Chloride (PVC)	5 kVDC
Belden Inc. 9899 009500	UL Style 1855	18 AWG	0.048 in	1.22 mm		500 '	152.4 m	0.144 in	3.66 mm	65	36	Copper Tinned	Poly-Vinyl Chloride (PVC)	5 kVDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 2.04

General part information

18 AWG Test Lead Wire 65/36 White 5000V 500.0' (152.4m)
