1845315
ActivePhoenix Contact
TERM BLOCK HDR 32POS VERT 2.54MM
1845315
ActivePhoenix Contact
TERM BLOCK HDR 32POS VERT 2.54MM
Description
General part information
1845315
32 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.100" (2.54mm) Vertical Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 1845315 |
|---|---|
| Color | Black |
| Contact Mating Finish | Gold |
| Current - IEC | 6 A |
| Current - UL | 6 A |
| Features | Solder Retention |
| Header Orientation | Vertical |
| Mounting Type | Surface Mount |
| Number of Levels | 2 |
| Number of Positions | 32 |
| Pitch | 0.1 in |
| Positions Per Level | 16 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 160 V |
| Voltage - UL | 150 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
