Specification	BC-CTS-152510

Area (L x W)	58.1 in²
Color	Light Gray, Clear Cover
Container Type	Box
Design	Lift-Off Screw Cover
Features	Sealing Gasket, Wall Mount, Flame Retardant
Height	3.937 in
Material	Polycarbonate, Fiberglass, Plastic
Material Flammability Rating	UL94 V-0, UL94 5VA, UL94 HB
Ratings	IP66, IP67, NEMA 4X, 6, UL 508A
Size / Dimension Length	9.843 in
Size / Dimension Width	5.906 in

BC-CTS Series

Part	Area (L x W)	Material	Material Flammability Rating	Height	Ratings	Color	Features	Size / Dimension Length	Size / Dimension Width	Container Type	Design
Boxco BC-CTS-080806	9.92 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.362 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	3.15 in	3.15 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-151507	34.9 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.953 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	5.906 in	5.906 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-101807	28.7 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.756 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	7.283 in	3.937 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-121207	24.2 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.953 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	4.921 in	4.921 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-283813	165 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	5.118 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	14.961 in	11.024 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-193818	112 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	7.087 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	14.961 in	7.48 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-152007	46.5 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.953 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	7.874 in	5.906 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-082507	31 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.756 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	9.843 in	3.15 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-081807	22.3 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	2.756 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	7.087 in	3.15 in	Box	Lift-Off Screw Cover
Boxco BC-CTS-152013	46.5 in²	Fiberglass Plastic Polycarbonate	UL94 5VA UL94 HB UL94 V-0	5.118 in	6 IP66 IP67 NEMA 4X UL 508A	Clear Cover Light Gray	Flame Retardant Sealing Gasket Wall Mount	7.874 in	5.906 in	Box	Lift-Off Screw Cover
