P33-24T
ActivePolytron
AC/DC CONVERTER +/-24V
Deep-Dive with AI
Search across all available documentation for this part.
P33-24T
ActivePolytron
AC/DC CONVERTER +/-24V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | P33-24T |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Current - Output 1 | 100 mA |
| Current - Output 2 | 100 mA |
| Mounting Type | Chassis Mount |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -25 °C |
| Size / Dimension [x] | 4.1 " |
| Size / Dimension [x] | 104.1 mm |
| Size / Dimension [y] | 63.5 mm |
| Size / Dimension [y] | 2.5 in |
| Size / Dimension [z] | 1.25 " |
| Size / Dimension [z] | 31.8 mm |
| Type | Enclosed |
| Voltage - Input [Max] | 125 VAC |
| Voltage - Input [Min] | 105 VAC |
| Voltage - Output 1 | 24 V |
| Voltage - Output 2 | -24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 200.98 | |
| 5 | $ 192.95 | |||
| 10 | $ 189.59 | |||
| 25 | $ 185.24 | |||
| 50 | $ 182.02 | |||
Description
General part information
P33-24T
Enclosed AC DC Converters 2 Output 24V -24V 105 ~ 125 VAC Input
