MRF6 Series

...

Part	Current - Test	Voltage - Test	Package Name	Gain	Package / Case	Power - Output	Technology	Mounting Type	Voltage - Rated	Frequency	Frequency (Min)	Frequency (Max)
NXP USA Inc. MRF6V14300HSR3	150 mA	50 V	NI-780S	18 dB	NI-780S	330 W	LDMOS	Chassis Mount	100 VAC/DC	1.4 GHz
NXP USA Inc. MRF6S19120HR5	1 A	28 V	NI-780H-2L	15 dB	SOT-957A	19 W	LDMOS		68 V	1.99 GHz
NXP USA Inc. MRF6S27085HR3	900 mA	28 V	NI-780H-2L	15.5 dB	SOT-957A	20 W	LDMOS		68 V	2.66 GHz
NXP USA Inc. MRF6V4300NBR5	900 mA	50 V	TO-272 WB-4	22 dB	TO-272BB	300 W	LDMOS	Chassis Mount	110 VAC	450 MHz
NXP USA Inc. MRF6V12250HSR3	100 mA	50 V	NI-780S	20.3 dB	NI-780S	275 W	LDMOS	Chassis Mount	100 VAC/DC	1.03 GHz
NXP USA Inc. MRF6V2010NR1	30 mA	50 V	TO-270-2	23.9 dB	TO-270AA	10 W	LDMOS	Surface Mount	110 VAC	220 MHz
NXP USA Inc. MRF6S19140HR5	1.15 A	28 V	NI-880	16 dB	NI-880	29 W	LDMOS		68 V		1.93 GHz	1.99 GHz
NXP USA Inc. MRF6V13250HR5	100 mA	50 V	NI-780H-2L	22.7 dB	SOT-957A	250 W	LDMOS		120 VDC	1.3 GHz
NXP USA Inc. MRF6P9220HR3	1.6 A	28 V	NI-860C3	20 dB	NI-860C3	47 W	LDMOS		68 V	880 MHz
NXP USA Inc. MRF6S21140HR3	1.2 A	28 V	NI-880H-2L	15.5 dB	SOT-957A	30 W	LDMOS	Chassis Mount	68 V	2.12 GHz
