Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1607057 | SM Series |
|---|---|---|
| Connector Type | - | Receptacle Housing |
| Contact Finish | Gold | Gold |
| Contact Shape | - | Circular |
| Contact Size | 3.6 mm | 3.6 mm |
| Contact Size | - | 2 mm |
| Contact Size | - | 3.6 mm |
| Contact Termination | Crimp | Crimp |
| Contact Type | Pin | Crimp, Pin |
| Fastening Type | - | Push-Twist |
| Features | - | Backshell |
| Housing Color | - | Silver |
| Ingress Protection | - | IP67 - Dust Tight, Waterproof |
| Insert Material | - | Polyamide (PA66), Nylon 6/6 |
| Mounting Type | - | Free Hanging (In-Line) |
| Note | - | Contacts Not Included |
| Number of Positions | - | 3 |
| Number of Positions | - | 8 |
| Number of Positions | - | 4 |
| Number of Positions | - | PE |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Orientation | - | N |
| Shell Material | - | Gadolinium-Zinc |
| Shell Size - Insert | - | M40-8 |
| Shielding | - | Shielded |
| Type | Power, Machined | For Male Pins, Power, Machined |
| Wire Gauge or Range - AWG [Max] | 18 AWG | 18 AWG |
| Wire Gauge or Range - AWG [Min] | 14 AWG | 14 AWG |
| Wire Gauge or Range - mm˛ [Max] | 2.5 mm˛ | 2.5 mm˛ |
| Wire Gauge or Range - mm˛ [Min] | 1 mm˛ | 1 mm˛ |
| Wire Gauge or Range - mm² [Max] | 2.5 mm² | 2.5 mm² |
| Wire Gauge or Range - mm² [Min] | 1 mm² | 1 mm² |
SM Series
Basic / Snap Action Switches Subminiature Basics
| Part | Features | Shielding | Note | Shell Size - Insert | Operating Temperature [Max] | Operating Temperature [Min] | Connector Type | Contact Shape | Orientation | Ingress Protection | Contact Size [custom] | Contact Size [custom] | Type | Insert Material | Contact Type | Mounting Type | Number of Positions [custom] | Number of Positions [custom] | Number of Positions [custom] | Number of Positions | Fastening Type | Housing Color | Shell Material | Contact Termination | Wire Gauge or Range - mm˛ [Min] | Wire Gauge or Range - mm˛ [Max] | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] | Wire Gauge or Range - mm² [Min] | Wire Gauge or Range - mm² [Max] | Contact Finish | Contact Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1613433 | Backshell | Shielded | Contacts Not Included | M40-8 | 125 °C | -40 °C | Receptacle Housing | Circular | N | IP67 - Dust Tight, Waterproof | 2 mm | 3.6 mm | For Male Pins | Polyamide (PA66), Nylon 6/6 | Crimp | Free Hanging (In-Line) | 3 | 8 | 4 | PE | Push-Twist | Silver | Gadolinium-Zinc | |||||||||
Phoenix Contact 1607057 | Power, Machined | Pin | Crimp | 1 mm˛ | 2.5 mm˛ | 18 AWG | 14 AWG | 1 mm² | 2.5 mm² | Gold | 3.6 mm |
