OKI-78SR-3.3/1.5-W36E-C
ActiveMurata Power Solutions Inc.
MODULE DC-DC 12VIN 1-OUT 3.3V 1.5A 4.95W 3-PIN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
OKI-78SR-3.3/1.5-W36E-C
ActiveMurata Power Solutions Inc.
MODULE DC-DC 12VIN 1-OUT 3.3V 1.5A 4.95W 3-PIN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | OKI-78SR-3.3/1.5-W36E-C | OKI-78SR Series |
|---|---|---|
| - | - | |
| Applications | ITE (Commercial) | ITE (Commercial) |
| Current - Output (Max) [Max] | 1.5 A | 1.5 A |
| Efficiency | 85.5 % | 85.5 - 90.5 % |
| Features | SCP | SCP |
| Mounting Type | Through Hole | Through Hole |
| Number of Outputs | 1 | 1 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 3-SIP Module | 3-SIP Module |
| Power (Watts) | 5 W | 5 - 8 W |
| Size / Dimension [x] | 11.9 mm | 10.4 - 18 mm |
| Size / Dimension [x] | 0.47 in | 0.41 - 0.71 in |
| Size / Dimension [y] | 10 mm | 7.6 - 11.9 mm |
| Size / Dimension [y] | 0.39 " | 0.3 - 0.47 " |
| Size / Dimension [z] | 0.69 " | 0.37 - 0.69 " |
| Size / Dimension [z] | 17.6 mm | 9.5 - 17.6 mm |
| Type | Linear Regulator Replacement | Linear Regulator Replacement |
| Voltage - Input (Max) [Max] | 36 V | 36 V |
| Voltage - Input (Min) [Min] | 7 V | 7 V |
| Voltage - Output 1 | 3.3 V | 3.3 - 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 6.81 | |
| 5 | $ 6.76 | |||
| 10 | $ 6.70 | |||
| 25 | $ 6.61 | |||
| 50 | $ 6.41 | |||
| 100 | $ 5.98 | |||
| 250 | $ 5.75 | |||
OKI-78SR Series
Non-Isolated DC/DC Converters 4.95W 12VIN 3.3VOUT 1.5A DC/DC
| Part | Features | Applications | Voltage - Output 1 | Efficiency | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Current - Output (Max) [Max] | Number of Outputs | Power (Watts) | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Package / Case | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. OKI-78SR-3.3/1.5-W36E-C | SCP | ITE (Commercial) | 3.3 V | 85.5 % | 11.9 mm | 0.69 " | 17.6 mm | 10 mm | 0.39 " | 0.47 in | 85 °C | -40 °C | Through Hole | 1.5 A | 1 | 5 W | 36 V | 7 V | 3-SIP Module | Linear Regulator Replacement |
Murata Power Solutions Inc. OKI-78SR-5/1.5-W36HE-C | SCP | ITE (Commercial) | 5 V | 90.5 % | 18 mm | 0.37 in | 9.5 mm | 11.9 mm | 0.47 " | 0.71 " | 85 °C | -40 °C | Through Hole | 1.5 A | 1 | 8 W | 36 V | 7 V | 3-SIP Module | Linear Regulator Replacement |
Murata Power Solutions Inc. OKI-78SR-3.3/1.5-W36-C | SCP | ITE (Commercial) | 3.3 V | 85.5 % | 10.4 mm | 0.65 in | 16.5 mm | 7.6 mm | 0.3 " | 0.41 " | 85 °C | -40 °C | Through Hole | 1.5 A | 1 | 5 W | 36 V | 7 V | 3-SIP Module | Linear Regulator Replacement |
Murata Power Solutions Inc. OKI-78SR-5/1.5-W36E-C | ||||||||||||||||||||
Murata Power Solutions Inc. OKI-78SR-5/1.5-W36E-C | ||||||||||||||||||||
Murata Power Solutions Inc. OKI-78SR-3.3/1.5-W36E-C | ||||||||||||||||||||
Murata Power Solutions Inc. OKI-78SR-5/1.5-W36-C | ||||||||||||||||||||
Murata Power Solutions Inc. OKI-78SR-3.3/1.5-W36-C | ||||||||||||||||||||
Murata Power Solutions Inc. OKI-78SR-3.3/1.5-W36-C | ||||||||||||||||||||
Murata Power Solutions Inc. OKI-78SR-5/1.5-W36-C |
Description
General part information
OKI-78SR Series
Non-Isolated DC/DC Converters 4.95W 12VIN 3.3VOUT 1.5A DC/DC
