General part information
Circuit Breakers CBE T11-818-1.8
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 4400.0515 |
|---|---|
| Actuator Type | Push to Reset |
| Approval Agency | UL1077, IEC 60934, GB 17701, CSA C22.2 No 235, EN 60934 |
| Breaker Type | Thermal |
| Current Rating (Amps) | 5 A |
| Number of Poles | 1 |
| Voltage Rating - AC | 240 V |
| Voltage Rating - DC | 48 V |
Circuit Breakers CBE T11-818-1.8
| Part | Number of Poles | Approval Agency | Current Rating (Amps) | Voltage Rating - DC | Breaker Type | Voltage Rating - AC | Actuator Type |
|---|---|---|---|---|---|---|---|
SCHURTER Inc. 4400.0515 | 1 | CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077 | 5 A | 48 V | Thermal | 240 V | Push to Reset |
