GSP1.8100.1

Active

SCHURTER Inc.

PWR ENT RCPT IEC320-C18 PNL SLDR

Search across all available documentation for this part.

Active

SCHURTER Inc.

PWR ENT RCPT IEC320-C18 PNL SLDR

Technical Specifications

Parameters and characteristics for this part

Specification	GSP1.8100.1

Accomodates a Fuse	False
Approval Agency	ENEC, CCC, cURus
Connector Style	IEC 320-C18
Connector Type	Male Blades, Receptacle
Current Rating - Appliance Inlet	10 A
Filter Type	Unfiltered - Commercial
Ingress Protection	IP40
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Flange, Through Hole, Right Angle
Number of Positions	2
Panel Cutout Dimensions [x]	30.3 mm
Panel Cutout Dimensions [y]	22.5 mm
Panel Thickness	3 mm
Panel Thickness	0.118 in
Termination	Solder
Voltage Rating - Appliance Inlet	250 VAC

PWR ENT RCPT IEC320-C18 PNL SLDR

Part	Mounting Type	Current Rating - Appliance Inlet	Approval Agency	Connector Type	Ingress Protection	Filter Type	Voltage Rating - Appliance Inlet	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Material Flammability Rating	Connector Style	Number of Positions	Panel Thickness	Panel Thickness	Accomodates a Fuse	Termination
SCHURTER Inc. GSP1.8100.1	Panel Mount, Flange, Through Hole, Right Angle	10 A	CCC, cURus, ENEC	Male Blades, Receptacle	IP40	Unfiltered - Commercial	250 VAC	30.3 mm	22.5 mm	UL94 V-0	IEC 320-C18	2	3 mm	0.118 in		Solder

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Power Entry Connector Receptacle, Male Blades IEC 320-C18 Panel Mount, Flange; Through Hole, Right Angle
